Concealed ceiling installation keeps the heater integrated with the pergola structure and saves floor space.
The IP65 rating provides protection against dust and water jets for outdoor applications.
Startup power begins at 33%, then switches to the previous heating level after 4 seconds.
Power can be adjusted between low, medium, and high levels through the reset control.
The heating-up function directly switches to the highest heating level, while the heating-down function reduces the output.
The remote uses 2 × AAA 1.5V batteries for convenient wireless operation.
Holding the reset button for at least 4 seconds restores the factory settings.
The Flush Mount Infrared Pergola Heater with Remote Control is a ceiling-integrated heating solution developed for pergolas and covered outdoor spaces. Its concealed installation keeps the overhead area clean while infrared radiation provides direct warmth without occupying floor space.
The unit works as an Infrared Patio Heater for outdoor living areas, with remote operation for convenient power adjustment.
The Flush Mount Infrared Pergola Heater suits residential and commercial outdoor spaces that require seasonal heating.
Outdoor Bars & Restaurants: An Infrared Patio Heater helps extend the usable period of open-air dining and seating areas.
Residential Pergolas: Suitable for patios, terraces, balconies, and garden pergolas where concealed installation is preferred.
Plazas & Public Areas: Provides supplementary heating for covered seating and outdoor activity areas.
Hospitality Projects: Suitable for hotels, resorts, restaurants, pergola manufacturers, contractors, and outdoor-space suppliers using a Smart Heater solution.
Work Areas: Can provide supplementary warmth for suitable outdoor construction and work environments.
OEM support is available for pergola manufacturers, distributors, contractors, and project suppliers of the Flush Mount Infrared Pergola Heater.
Mounting: Adapt installation details to different pergola ceiling structures.
Electrical Specifications: Customize voltage, frequency, power, and plug requirements for target markets.
Appearance: Adjust housing color and finish to coordinate with pergola frames.
Control: Coordinate remote-control functions and operating settings.
Documentation: Support customized labels, manuals, and technical documents.
System Matching: Integrate the Smart Heater with different pergola heating systems.
1. Is the heater suitable for open outdoor areas?
Yes. Its IP65 protection makes it suitable for appropriate outdoor installations exposed to dust and water jets.
2. Can an Infrared Patio Heater operate in different seasons?
Yes. The unit can provide supplementary outdoor heating during spring, summer, autumn, and winter according to local conditions.
3. What batteries does the remote control use?
It requires 2 × AAA 1.5V batteries. The same battery specification should be used for replacement.
4. What happens if an object blocks the remote signal?
The heater may not receive the command correctly. A clear path between the remote and receiver is recommended.
5. Can this Smart Heater be integrated into different pergola systems?
Yes. Its mounting, electrical specifications, appearance, and control settings can be customized to match different pergola structures and heating system requirements.
6. Who should perform electrical installation or repairs?
Qualified electricians or authorized professional service personnel should handle installation and maintenance for electrical safety.
| Item | Parameter |
| Model | LDHR009‑150KY |
| Voltage (V) | 120V~ |
| Power consumption (W) | 1500W |
| Dimensions L×W×H (mm) | 656.0×140.0×110.0 |
| Weight (kg) | 3.5KG |
| IP code | IP65 |
| Infrared receiving Angle | 60°±5° |
